Industrial monitors touch screens have a wide range of applications in the production process.
These touch screen displays can meet stringent requirements such as ingress protection requirements, anti-vandal requirements, high resolution requirements, etc.
IP-rated touchscreen monitors protect the screen from contaminants such as dust, water, and oil.
Wireless industrial displays can present data in real time in any environment, increasing the safety and efficiency of on-site operations. Sun-readable displays are water-resistant, reflective, and high-brightness, allowing them to be used in bright light such as outdoors.
The fully enclosed touch screen panel can prevent all kinds of dust and grease from entering the equipment, and provide more reliable protection for the equipment. Anti-glare industrial displays eliminate light reflections that distract operators.
The touch-enabled industrial computer has a sensitive touch screen, which makes it easier for operators to grasp the production process.
Capacitive touch screen displays can provide more accurate, faster and more flexible operator control. Industrial touch screens are widely used in fields such as factory automation, logistics management, production monitoring and intelligent control.
Display | Screen Size | 21.5 inch | |||
Screen Resolution | 1920*1080 | ||||
Luminous | 250 cd/m2 | ||||
Color Quantitis | 16.7M | ||||
Contrast | 1000:1 | ||||
Visual Range | 85/85/80/80 (Typ.)(CR≥10) | ||||
Display Size | 476.64(W)×268.11(H) mm | ||||
Touch parameter | Reaction Type | Electric capacity reaction | |||
Lifetime | More than 50 miliion times | ||||
Surface Hardness | >7H | ||||
Effective Touch Strength | 45g | ||||
Glass Type | More than 50 miliion times | ||||
Luminousness | >85% | ||||
Parameter | Power suplier mode | 12V/5A external power adapter / industral interface | |||
Power specs | 100-240V,50-60HZ | ||||
Imput voltage | 9-36V/12V | ||||
Anti-static | Contact discharge 4KV-air discharge 8KV(customization available≥16KV) | ||||
Rate of work | ≤18W | ||||
Vibration proof | GB242 standard | ||||
Anti-interference | EMC|EMI anti-electromagnetic interference | ||||
Protection | Front panel IP65 dustproof waterproof | ||||
Color of shell | Black | ||||
Install mode | Embedded snap-fit/wall hanging/desktop louver bracket/foldable base/cantilever type | ||||
Environment temperature | <80%,Condesation forbidden | ||||
Working temperature | Working:-10 ~ 60 °C;Storage -20 ~ 70 °C | ||||
Language menu | Chinese、English、Gemman、French、Korean、Spanish、Italia、Russia | ||||
Guarantee | Whole computer free for maintain in 1 year | ||||
Maintenance terms | Three guarantee: 1guarantee repair,2guarantee replacement,3guarantee sales return.Mail for maintain | ||||
I/O interface parameter | DC port 1 | 1*DC12V/5525 socket | |||
DC port 2 | 1*DC9V-36V/5.08mm phoneix 3 pin | ||||
Touch function | 1*USB-B external interface | ||||
VGA | 1*VGA IN | ||||
HDMI | 1*HDMI IN | ||||
DVI | 1*DVI IN | ||||
PC AUDIO | 1*PC AUDIO | ||||
EARPHONE | 1*earphone | ||||
Packing list | N.W. | 5.5KG | |||
Product size | 560*358*66mm | ||||
Range for embedded trepanning | 536.3*340mm | ||||
Carton size | 645*443*125mm | ||||
Power adapter | Optional | ||||
Power line | Optional | ||||
Parts for install | Three guarantee: 1guarantee repair,2guarantee replacement,3guarantee sales return.Mail for maintain |
