17 inch embedbed industrial panel monitor with touch screen dispaly

Short Description:

Introducing our cutting-edge 17-inch Industrial Panel Monitor, the perfect solution for your embedded display needs.Designed with advanced technology and a sleek design, this monitor offers exceptional performance and versatility.

Featuring a high-resolution touch screen, users can easily navigate through applications and interact with the display effortlessly. The touch screen is responsive and durable, ensuring accurate and smooth operation even in demanding industrial environments.With its embedded capabilities, this monitor is ideal for integration into various industrial applications such as manufacturing plants, control rooms, and automation systems.

size: 17"

Screen Resolution: 1280*1024

Luminous: 250 cd/m2

Color Quantitis: 16.7M

Contrast: 1000:1

Download as pdf whatsapp email

Product Detail

Display Parameter

Touch Parameter

Other Parameter

Product Tags

10.1"

15.6 "

17 "

18.5 "

19 "

21.5 "

10.1"

Display	Screen Size	10.1 inch
	Screen Resolution	1280*800
	Luminous	350 cd/m2
	Color Quantitis	16.7M
	Contrast	1000:1
	Visual Range	85/85/85/85(Typ.)(CR≥10)
	Display Size	217 (W) × 135.6 (H)mm

15.6 "

Display	Screen Size	15.6 inch
	Screen Resolution	1920*1080
	Luminous	300 cd/m2
	Color Quantitis	16.7M
	Contrast	800:1
	Visual Range	85/85/85/85 (Typ.)(CR≥10)
	Display Size	344.16(W)×193.59(H) mm

17 "

Display	Screen Size	17 inch
	Screen Resolution	1280*1024
	Luminous	250 cd/m2
	Color Quantitis	16.7M
	Contrast	1000:1
	Visual Range	89/89/89/89 (Typ.)(CR≥10)
	Display Size	337.92(W)×270.336(H) mm

18.5 "

Display	Screen Size	18.5 inch
	Screen Resolution	1920*1080
	Luminous	250 cd/m2
	Color Quantitis	16.7M
	Contrast	1000:1
	Visual Range	89/89/89/89 (Typ.)(CR≥10)
	Display Size	408.96(W)×230.04(H) mm

19 "

Display	Screen Size	19 inch
	Screen Resolution	1280*1024
	Luminous	250 cd/m2
	Color Quantitis	16.7M
	Contrast	1000:1
	Visual Range	89/89/89/89 (Typ.)(CR≥10)
	Display Size	374.784(W)×299.827(H) mm

21.5 "

Display	Screen Size	21.5 inch
	Screen Resolution	1920*1080
	Luminous	250 cd/m2
	Color Quantitis	16.7M
	Contrast	1000:1
	Visual Range	85/85/80/80 (Typ.)(CR≥10)
	Display Size	476.64(W)×268.11(H) mm

Compt industrial panel monitor:

7*24 continuous operation

dustproof and waterproof

adapt to harsh environment

aluminum alloy material

fast heat dissipation

customized according to requirements

Its compact size and rugged construction make it suitable for space-constrained environments while providing reliable operation in harsh conditions.

The 17-inch display offers a vibrant and crisp viewing experience, presenting graphical data and information with utmost clarity.

17 inch embedbed industrial panel monitor

Its wide viewing angles enable clear visibility from different directions, ensuring that critical information is easily accessible to multiple users.

Built with industry-grade materials, this monitor is designed to withstand extreme temperatures, dust, vibrations, and other challenging conditions.

Support a variety of interfaces and extensions :

USB, DC, RJ45, audio, HDMI, CAN, RS485, GPIO, etc.,

can be connected with a variety of peripherals.

Previous: 15.6 inch embedded industrial touchscreen fanless pc computers

Next: 21.5 ” I5-6300u wall-mounted Industrial All-In-One Panel Pc With Touch Screen Monitor

Screen	17 inch
Resolution	1280*1024
Brightness	250 cd/m2
Color	16.7M
Contrast	1000:1
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)
Display area	337.92(W)×270.336(H) mm

Reaction Type	Capacitive touch（Optional non-touch，resistive touch ）
Lifetime	＞50 millions times
Surface Hardness	＞7H
Effective Touch Strength	45g
Glass Type	Hardened glass
Luminousness	＞85%

Input power	12V4A
anti-static	Contact 4KV- air 8KV (can be customized ≥16KV)
Power	≈10W
Anti-Shock	GB242 standard
Anti-interference	EMC\|EMI Anti-electromagnetic interference
Dustproof and waterproof	Front panel IP65 dustproof and waterproof
Case color	Black
installation method	Built-in edge, desktop, wall hanging, cantilever, etc
Ambient temperature	≤95%，No-condensing
Operating temperature	Working：-10 ~ 60 °C；Storage-20 ~ 70 °C
language menu	Chinese, English, German, French, Korean, Spanish, Italian, Russian
Warranty	1 YEAR
Interfaces	1DC12V、1USB-B、1VGA、1HDMI
