17.3 inch industrial touch screen monitor with Touch parameter Lifetime More than 50 miliion times

Short Description:

COMPT Industrial PC touch screens are computer devices widely used in industrial environments to provide operators with reliable, precise and safe control and monitoring. They are installed in machines, equipment and vehicles for functions such as data acquisition, control adjustment and information display. These devices are widely used in many fields such as industrial automation, intelligent manufacturing, logistics, transportation, and healthcare.


  • Model: CPT-173MXBC3
  • Screen Size: 17.3 inch
  • Screen Resolution: 1920*1080
  • Luminous: 250 cd/m2
  • Color Quantitis: 16.7M
  • Contrast: 800:1
  • Product Detail

    Product Tags

    Industrial pc touch screen Video:

    Industrial pc touch screen

    This video shows the product in 360 degrees.
    Product resistance to high and low temperature, fully closed design to achieve IP65 protection effect, can 7*24H continuous stable operation, support a variety of installation methods, a variety of sizes can be selected, support customization.
    Used in industrial automation, intelligent medical, aerospace, GAV car, intelligent agriculture, intelligent transportation and other industries.

    Features of  industrial pc touch screen:

    Industrial PC touch screens are computer devices widely used in industrial environments to provide operators with reliable, precise and safe control and monitoring. They are installed in machines, equipment and vehicles for functions such as data acquisition, control adjustment and information display. These devices are widely used in many fields such as industrial automation, intelligent manufacturing, logistics, transportation, and healthcare.

    Industrial PC touch screens have many outstanding features. First, their housings are usually made of metal materials and industrial designs, which ensure their adaptability to harsh environments and the ability to withstand various vibrations, shocks and temperatures. Secondly, the main components such as the main board, memory, and hard disk are specially designed to operate without trouble for a long time, ensuring the stability and reliability of the equipment. Finally, the industrial PC touch screen supports asynchronous, synchronous I/O, Ethernet and other interfaces to facilitate seamless connection and collaboration with other devices.

    In addition to these features, industrial PC touch screens have a wide range of applications. In smart manufacturing, they can help companies improve production efficiency and quality, and reduce costs and energy consumption. In logistics transportation, they can realize the tracking of goods, vehicles and warehouses and the management of logistics information. In healthcare, they can help doctors and nurses manage and maintain medical equipment, improving the quality and efficiency of medical services. It can be seen that industrial PC touch screens play a decisive role in modern industrial production and daily life, and their application prospects are still broad.

    industrial pc touch screen
    industrial panel pc touch screen

    Hardware Configuration information:

    Display Screen Size 17.3 inch
    Screen Resolution 1920*1080
    Luminous 250 cd/m2
    Color Quantitis 16.7M
    Contrast 800:1
    Visual Range 85/85/85/85 (Typ.)(CR≥10)
    Display Size 381.888(W)×214.812(H) mm
    Touch parameter Reaction Type Electric capacity reaction
    Lifetime More than 50 miliion times
    Surface Hardness >7H
    Effective Touch Strength 45g
    Glass Type More than 50 miliion times
    Luminousness >85%
    Parameter Power suplier mode 12V/5A external power adapter / industral interface
    Power specs 100-240V,50-60HZ
    Imput voltage 9-36V/12V
    Anti-static Contact discharge 4KV-air discharge 8KV(customization available≥16KV)
    Rate of work ≤18W
    Vibration proof GB242 standard
    Anti-interference EMC|EMI anti-electromagnetic interference
    Protection Front panel IP65 dustproof waterproof
    Color of shell Black
    Install mode Embedded snap-fit/wall hanging/desktop louver bracket/foldable base/cantilever type
    Environment temperature <80%,Condesation forbidden
    Working temperature Working:-10 ~ 60 °C;Storage -20 ~ 70 °C
    Language menu Chinese、English、Gemman、French、Korean、Spanish、Italia、Russia
    Guarantee Whole computer free for maintain in 1 year
    Maintenance terms Three guarantee: 1guarantee repair,2guarantee replacement,3guarantee sales return.Mail for maintain
    I/O interface parameter DC port 1 1*DC12V/5525 socket
    DC port 2 1*DC9V-36V/5.08mm phoneix 3 pin
    Touch function 1*USB-B external interface
    VGA 1*VGA IN
    HDMI 1*HDMI IN
    DVI 1*DVI IN
    PC AUDIO 1*PC AUDIO
    EARPHONE 1*earphone
    Packing list N.W. 4.5KG
    Product size 454*294*61mm
    Range for embedded trepanning 436*276mm
    Carton size 539*379*125mm
    Power adapter Optional
    Power line Optional
    Parts for install Three guarantee: 1guarantee repair,2guarantee replacement,3guarantee sales return.Mail for maintain



    Industrial pc touch screen solution:

    Industrial computer in AGV Forklift solutions
    Industrial computers in Intelligent Transportation solutions
    Industrial Android All-in-One Solution in Smart Home Robotics
    Industrial android panel cp in cnc machine Solutionr
    industrial computer Heavy Industry Equipment Solution
    Industrial computers in intelligent security solutions
    https://www.gdcompt.com/solution/smart-agriculture-solution/
    Hospital self-service inquiry and payment equipment

    Industrial tablet android Engineering dimention drawing:

    industrial pc touch screen
