12 Inch Industrial Touch Screen Monitor Panel Pc Computer

Short Description:

Name: Industrial Touch Screen Monitor
Screen Size: 12 inch
Screen Resolution: 1024*768
Luminous: 400 cd/m2
Color Quantitis: 16.2M
Contrast: 500:1
Visual Range: 89/89/89/89 (Typ.)(CR≥10)
Display Size: 246(W)×184.5(H) mm

Download as pdf whatsapp email

Product Detail

Product Tags

Products Video

Products Information:

COMPT brand as a well-known manufacturer with 9 years of experience in manufacturing industrial panel PC, independent research and development production of 12-inch industrial touch screen computer monitor panel PC, with leading technology and stability, by the majority of customers trust and praise.

This 12-inch industrial touch screen monitor panel PC adopts customised design, which can be personalised according to customers' needs to meet various application requirements in different industries. Embedded design, simple and atmospheric appearance, black shell, suitable for a variety of industrial occasions.

https://www.gdcompt.com/12-inch-industrial-touch-screen-monitor-panel-pc-computer-product/

Industrial Touch Screen Monitor screen adopts capacitive touch technology with excellent sensitivity and response speed, which can achieve precise touch operation. The display resolution reaches 1024*768, the display effect is clear and delicate, and it can meet the strict requirements for display effect in industrial environment.

This Industrial Touch Screen Monitor is equipped with DK-RTD2522 motherboard, which has stable and reliable performance and can adapt to various complex industrial environments. The touch screen adopts TYPE-B touch technology and supports multi-touch, which makes the operation more convenient and flexible and improves work efficiency.

Products Parameter:

Display	Screen Size	12 inch
	Screen Resolution	1024*768
	Luminous	400 cd/m2
	Color Quantitis	16.2M
	Contrast	500:1
	Visual Range	89/89/89/89 (Typ.)(CR≥10)
	Display Size	246(W)×184.5(H) mm
Touch parameter	Reaction Type	Electric capacity reaction
	Lifetime	More than 50 miliion times
	Surface Hardness	＞7H
	Effective Touch Strength	45g
	Glass Type	More than 50 miliion times
	Luminousness	＞85%
Parameter	Power suplier mode	12V/5A external power adapter / industral interface
	Power specs	100-240V，50-60HZ
	Imput voltage	9-36V/12V
	Anti-static	Contact discharge 4KV-air discharge 8KV（customization available≥16KV）
	Rate of work	≤8W
	Vibration proof	GB242 standard
	Anti-interference	EMC\|EMI anti-electromagnetic interference
	Protection	Front panel IP65 dustproof waterproof
	Color of shell	Black
	Environment temperature	<80%,Condesation forbidden
	Working temperature	Working：-10°~60°；Storage：-20°~70°
	Language menu	Chinese、English、Gemman、French、Korean、Spanish、 Italia、Russia
	Install mode	Embedded snap-fit/wall hanging/desktop louver bracket/foldable base/cantilever type
	Guarantee	Whole computer free for maintain in 1 year
	Maintenance terms	Three guarantee: 1guarantee repair,2guarantee replacement,3guarantee sales return.Mail for maintain
I/O interface parameter	DC电源1	1*DC12V/5525 socket
	DC电源2	1*DC9V-36V/5.08mm phoneix 3 pin
	触摸接口	1*USB-B external interface
	VGA	1*VGA IN
	HDMI	1*HDMI IN
	DVI	1*DVI IN
	PC AUDIO	1*PC AUDIO
	EARPHONE	1*earphone
Packing list	N.W.	3.5KG
	Product size	31725262mm
	Range for embedded trepanning	303*238mm
	Carton size	402337125mm
	Power adapter	Optional
	Power line	Optional
	Parts for install	Embedded snap-fit * 4，PM4x30 screw * 4

Engineering Dimention Drawing:

Product Solutions：

To ensure stable displays in vibrating environments, our industrial monitors are designed to withstand shock. Whether in applications such as transportation, marine, military equipment, etc., our products are able to withstand vibration and shock and maintain a stable display.

We use high quality aluminium alloy material to ensure that our industrial monitors have excellent durability and heat dissipation performance. This not only allows our products to operate stably for long periods of time in the working environment, but also effectively protects the electronic components inside the display.

As our customer, you can also enjoy our custom design service. We can provide you with individual industrial display solutions according to your specific needs and requirements. Whether it is the design, interface options or configuration of special functions, we can meet your needs.

When you choose our industrial monitors, you will get excellent display, durable quality, reliable performance, and a full range of after-sales services. We are committed to providing our customers with the best industrial display solutions, exceeding your expectations, and becoming a trusted partner for long-term cooperation. If you have any questions or need more information, please feel free to contact us.
